Tech Specifications

Hardware
Device Interfaces

• Two USB 3.0 Type-A (female) ports
• One USB 3.0 Type-C port with power delivery of up
to 100 W (20 V @ 5 A)
• HDMI Port (3840 x 2160 or 4096 x 2160 pixels @ 60
Hz) backwards compatible to 1080p and 720p
• USB Type-C Connector (Thunderbolt 3 / 4 compliant)
• One 3.5mm audio port

Power Delivery

• USB Type-C port: 20 V @ 5 A

General
Standards

• HDM 1.4
• HDCP 2.2
• DisplayPort Alternate Mode
• USB Specification Version 3.0/2.0/1.1

Minimum System Requirements

• Computer running Microsoft Windows, Mac OS or
Chrome OS
• A USB Type-C Port with DisplayPort Alternate Mode
support

Power

• Input: Bus-powered
• Consumption: 70 mA, 5V DC

Temperature

• Operating: 0 to 70 °C (32 to 158 °F
• Storage: -25 to 85 °C (-13 to 185 °F)

Humidity

• Operating: 5% to 80% RH, non-condensing
• Storage: 5% to 80% RH, non-condensing

Certifications

• CE
• FCC
• RoHS

Physical
Dimensions (W x H x D)

• 1 3 1 x 32 x 11 mm
• Cable length: 18cm

Weight

• 54.0 g
