• 48 Ports 25G SFP28 for downlink • 8 Ports 100G QSFP28 for uplink • 2 PSUs (1+1) redundant and hot-swappable • 5 FANs (n+1) redundant and hot-swappable • Pre-load with ONIE for SONiC OS • Support MC-LAG, EVPN, VxLAN, and VRF • Advanced Routing: BGP/OSPF/IS-IS, ECMP, BFD • Support 802.1Qbb (PFC) and 802.1Qaz (ETS) • IP interfaces: IPv4 up to 512K and IPv6 up to 256K • Support sFlow, REST API, ZTP, and CLI
48 x 25G SFP28 and 8 x 100G QSFP28 ports deliver massive bandwidth for data-intensive workloads
Open OS Architecture
SONiC-based open platform enables seamless integration, modular design, and long-term adaptability
Standard Routing Protocol
Support BGP-EVPN, VxLAN, MC-LAG, VRF, OSPF and ECMP for L3 routing and resilient network operation
Flexible VxLAN EVPN
Enable VxLAN and EVPN to simplify network virtualization and deliver efficient multi-tenant segmentation
Advanced Automation
Automates routing, security, and QoS with RIP, OSPF, VLAN, and ACL – improving efficiency and reducing overhead
Powers and Fans Redundancy
Front-to-back airflow, 1+1 hot-swappable PSUs, and N+1 fans ensure cooling and uptime reliability
Where Space is Tight, Performance is Mighty
Equipped with 48 x 25G SFP28 and 8 x 100G QSFP28 ports, this compact 1RU switch delivers up to 2 Tbps of non-blocking switching capacity, ideal for high-density aggregation or core roles. Front-to-back airflow, 1+1 hot-swappable redundant power supplies, and N+1 hot-swappable fans ensure optimal thermal performance and reliability. Making it a perfect fit for micro data centers and space-constrained environments.
Intelligent Traffic Management, Provisioning, and Visibility
Traffic monitoring demands high-availability, high-performance network infrastructure. The DQS-5000-56ZS meets these needs with MC-LAG, hot-swappable PSU and fans, 25G downlinks for endpoint aggregation, and 100G uplinks for database and storage connectivity.
It ensures uninterrupted data transfer, precise data retrieval, and intelligent event-based traffic forwarding. This enables seamless connectivity across racks or sites, supporting multi-tenant environments and virtualized workloads with the following benefits :
• Massive Network Scalability
• Full Bandwidth Utilization
• Seamless VM Mobility
• Optimized Data Center Efficiency
Increased Link Redundancy and Load Balancing
Multi-Chassis Link Aggregation Group (MC-LAG) is widely adopted in enterprise and data center networks to enhance network resiliency, bandwidth utilization, and seamless failover protection.
Unlike traditional LAG, MC-LAG allows devices to connect to two independent switches simultaneously, ensuring service continuity even if one switch becomes unavailable.
• High Availability - Dual-homing redundancy
• Load Balancing – Uninterrupted service
• Seamless Failover – Optimal performance
• Open Interoperability – Works with standard LAG protocols
Unmatched Speed, Energy Efficiency, and Reliability
As enterprise micro data center networks become increasingly dynamic and data-intensive, soaring bandwidth demands are driving the need for high-density 25G and 100G Ethernet switching across both leaf and spine tiers to ensure seamless scalability, low latency, and optimized performance.
The DQS-5000-56ZS – Purpose-built for micro data centers, optimized for high-speed Layer 3 traffic with ultra-low latency in a compact design. It delivers the speed, scalability, and efficiency needed for agile, future-ready data centers, integrating seamlessly with Layer 3 topologies, overlay networks, and both virtualized and traditional architectures.
Need help?
If you have any questions, you are always welcome to contact us. We'll get back to you as soon as possible.
Shipping Information
Use this text to answer questions in as much detail as possible for your customers.
Customer Support
Use this text to answer questions in as much detail as possible for your customers.
FAQ’s
Use this text to answer questions in as much detail as possible for your customers.
Contact Us
Use this text to answer questions in as much detail as possible for your customers.
Tech Specifications
Hardware
Console Port
1 x 10/100/1000Base-T RJ-45
USB Port
1 x USB Type A
Wireless
Interfaces
48 x 25G SFP28
8 x 100G QSFP28
Switch Capacity
2 Tbps
Max. Packet Forwarding Rate
2380 Mpps
General
Max Power Consumption
550W
Power Supply
CRPS, 1+1 Redundancy, Hot-Swappable
FAN
5 (n+1) Redundancy, Hot-Swappable
Actual performances may vary due to settings, cabling, temperature, network configuration, interface, device compatibility, environmental and on-site conditions, and other similar factors. References to power capability, signal or processing speed, signal range or distance, data encryption, storage capacity, display properties, or other performance metrics are based on optimal conditions derived from industry standards and provided for informational purposes only. Specifications may be subject to change without prior notice.
Physical
Dimensions
440 x 470 x 44 mm (17.32 x 18.50 x 1.73 in)
Weight
9.7 kg
Operating Temperature
0 - 40 °C (32 - 104 °F)
Operating Humidity
5% to 95% relative humidity
Storage Humidity
5% to 90% relative humidity
