Tech Specifications

General
Interfaces
  • 24 x 10GE PoE++
  • 4 x 10/25G SFP28
Switch Capacity
  • 680 Gbps
Max. Packet Forwarding Rate
  • 505.92 Mpps
PoE Standards
  • IEEE 802.3af/at/bt
PoE Power Budget
  • 790 W
Max Power Consumption
  • 1008.1 W
Surge Protection
  • IEC61000-4-5 6kV surge protection on all Ethernet ports
FAN
  • 2 x Smart fans
Console Port
Power Supply Type
  • Internal
Physical
Dimensions
  • 440 x 250 x 44 mm (17.32 x 9.84 x 1.73 in)
Weight
  • 6.48 kg (14.29 lbs)
Operating Temperature
  • 0 - 50 °C (32 - 122 °F)
Storage Temperature
  • -40 - 70°C (-40 - 158 °F)
Operating Humidity
  • 10% to 90% relative humidity
Storage Humidity
  • 5% to 90% relative humidity
